VL Series 13" Top-Mount Sand Filter System

Hayward

SKU: VL40T32

VL Series above-ground systems offer the performance and reliability expected from the world’s leading provider of above ground equipment.

Features

VL Series above-ground systems offer the performance and reliability expected from the world’s leading provider of above-ground equipment., The VL 40 series system is easy to assemble with an integrated pump base, an incredibly quiet pump and proven sand filter technology for trouble-free operation.

Features and Benefits

  • VL 40 series is designed for pools up to 10,000 gallons
  • Designed for quick assembly and precise alignment of components
  • Pumps and filters are performance-matched to provide maximum flow and energy efficiency
  • Multi-position valve provides maximum flow at low pressure drop
  • Durable filter bases for long-lasting, all-weather ­performance
  • Includes 13" Polymeric Tank, 4-Position Filter Valve, 30 GPM Pump, Integrated Pump Base, and 1 1⁄4" and 1 1⁄2" Hose Adapters
  • EXPERT LINE products can only be purchased through your local pool professional or in-store.  Exclusions, other terms, and conditions may apply.
  • 3+ Year Parts and Labor Warranties*

*When sold by a Hayward Rewards® partner. Exclusions, other terms and conditions may apply.

Brand Hayward
Channel Expert Line
GTIN 610377138932
Warranty - Labor None
Master Carton Qty 1
Pallet Qty 12
Warranty - Parts 2-year
Pool Type Above Ground
Product Dimensions 17.8 " x 13.4 " x 21.3 "
Product Height 17.8 in
Product Length 21.3 in
Product Weight 26 lb
Product Width 13.4 in
Shipping Dimensions 17.8 " x 13.4 " x 21.3 "
Shipping Weight 26 lb
Twist Lock No
Filter Type Pump Filter Systems
Series Filters VL Series
Turnover - 10 Hours —
Turnover - 8 Hours —
DOE Compliant Yes
Effective Filtration Area N/A
Number of Filter Elements 1
Total HP 0.5 HP
Valve Included N/A
Sand Capacity 42 lbs.
Parts Details

Click on the part number in the diagram to display the details.

Questions & Answers

15 answered question(s)

06/24/26

Q: Hello My question is regarding where the pump/filter meet! When pump is not running it leaks, but when turned on it doesn’t. I thought that it needed teflon tape, so I did that, but it still leaks. Any ideas or recommendations?

A:
Hi, give our Tech Support Group a call for help with this issue 908-355-7995

By Hayward Support

06/24/26

Q: Need hose for this sand filter pump

A:
Hi, we do not sell directly. You can find a local Hayward Authorized Dealer by clicking on the Dealer Locator tab on our home page of our website, Hayward.com Link to dealer locator: https://hayward.com/dealerlocator

By Hayward Support

06/24/26

Q: My filter vl40t32 is leaking water out of the top under the handle what is causing this is only the 3rd season we have had it

A:
Hi, give our Tech Support Group a call for help with this issue 908-355-7995

By Hayward Support

06/24/26

Q: What do I need to do when adding chlorine tabs into the basket

A:
You should never add tablets to the basket. For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: How many HP and what is largest size pool it can support 20 foot , 24 foot 48 “ deep ?

A:
Hi, the VL system is designed for pools up to 10,000 gallons and is rated at 30 gpm.

By Hayward Support

06/24/26

Q: Can I order just the straining kit fory pump? It cracked over winter

A:
Hi, we do not sell direct. You can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: The O-ring that fits onto the bottom opening of the multi-port valve, where the standpipe inserts broke. I ordered the O-ring replacement kit and then realized that particular O-ring is not part of the kit. How can I get a replacement for the O-ring that goes into the bottom opening of the multi-port valve? I’m worried that without it the stand pipe won’t seal properly and could result in a leak.

A:
Hi, someone from our Technical Service Department will contact you via email.

By Hayward Support

06/24/26

Q: I plug the pump in and it just a buzz. Is there something wrong or do I need a new one?

A:
Hi, it sounds like the pump is stuck. With the pump unplugged you can see if the impeller will turn freely. If not there may be something in the pump keeping if from turning. Otherwise, you would need to contact a service center for help in determining...

By Hayward Support

06/24/26

Q: Does the vl40t32 have an on of switch?

A:
It does not.

By Hayward Support

06/24/26

Q: How to drain water from the vl sand tank

A:
HI, you will need to remove the top and pour the water out of the filter tank.

By Hayward Support

06/24/26

Q: Hi How many bags of sand does this filter holds?

A:
Hi, it requires 42 lbs of sand.

By Hayward Support

06/24/26

Q: I am looking for a strainer housing for my VL40T32

A:
HI, the part number for the strainer kit is VLX4007K, we do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: Our pump has started shooting sand into the pool and the valve handle is not responding in any position. Thoughts for what we can do to remedy this?

A:
For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: Whats the price

A:
Hi, we do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: can I get a replacement hose from motor to sand filter?

A:
Hi, we do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Related Parts

STRAINER HOUSING KIT (Open Line)
STRAINER HOUSING KIT (Open Line)

SKU VLX4007K

STRAINER LID & BASKET (Open Line)
STRAINER LID & BASKET (Open Line)

SKU VLX4007A

MULTI-PORT VALVE (Open Line)
MULTI-PORT VALVE (Open Line)

SKU VLX4003A

PUMP W/O STRAINER (Open Line)
PUMP W/O STRAINER (Open Line)

SKU VLX4009

STAND PIPE & UNDERDRAIN ASSY (Open Line)
STAND PIPE & UNDERDRAIN ASSY (Open Line)

SKU VLX4001A

CLAMP HARDWARE & FILTER O-RING (Open Line)
CLAMP HARDWARE & FILTER O-RING (Open Line)

SKU VLX4002A

PUMP SHAFT SEAL (Open Line)
PUMP SHAFT SEAL (Open Line)

SKU VLX4008

PUMP TO FILTER HOSE (Open Line)
PUMP TO FILTER HOSE (Open Line)

SKU VLX4006A

Accessory Kit - VL Series (Open Line)
Accessory Kit - VL Series (Open Line)

SKU VLX4005A

VLX4004A O-RING KIT (Open Line)
VLX4004A O-RING KIT (Open Line)

SKU VLX4004A
