Universal HC Series Heater 400,000 BTU - Dual Fuel

Hayward

SKU: HDF400

Universal HC Series dual-fuel technology gas heaters are uniquely engineered for use with Hayward plumbing adapters, making them an easy drop-in replacement for other heater brands.

Replacement SKU: HDFS400

Features

Universal HC Series dual-fuel technology gas heaters are uniquely engineered for use with Hayward plumbing adapters, making them an easy drop-in replacement for other heater brands. The heat exchanger is made from cupro nickel for added reliability, and the easy-out air/gas mixing orifice makes propane conversion fast and simple. The small footprint with zero wall clearance fits in even the most compact equipment pads, while the refined gas controls and remote connectivity provide a simple user experience with added service convenience.

Features and Benefits

  • Top-access design eliminates the need to remove side panels and kneel during service
  • Low NOx emissions meet clean air quality standards and offer premium heating performance
  • Cupro nickel heat exchanger comes standard, protecting against water corrosion and natural wear
  • Zero wall clearance ensures a seamless fit in smaller equipment pads and tight spaces
  • Easy-out mixing orifice allows for easy in-field conversion between natural gas and propane
  • Quick-access reversible top easily swaps plumbing from from right to left while providing access to gas shutoff, voltage selection and more, all via a single fastener
  • Compact, lightweight design makes installation easy in any environment
  • Integral tie-down connections on the base make for easy hand truck transport with no extra tiedown brackets required
  • Patented butterfly bypass valve enables flow rates up to 125gpm without extra accessories
  • Exclusive plumbing adapters allow for simple drop-in replacement with no pipe cutting required
  • EXPERT LINE products can only be purchased through your local pool professional or in-store.  Exclusions, other terms, and conditions may apply.
  • 3+ Year Parts and Labor Warranties*

*When sold by a Hayward Rewards® partner. Exclusions, other terms and conditions may apply.

Active Defrost No
Application New Construction, Renovation, Aftermarket
Boost Mode No
Brand Hayward
Channel Expert Line
Circuit Amps 5.5
Compressor Speed N/A
Cooling Capability No
Fuel Type Dual Fuel
GTIN 610377402835
Heating Capacity (BTU/hr) 400,000
Hertz - Heaters 60 Hz
Kilowatts 117 kW
Warranty - Labor 1-year
Low Ambient Operation Yes
Master Carton Qty 1
Maximum Breaker Size (Amps) 15
Minimum Operating Temperature 40 °F
Pallet Qty 1
Warranty - Parts 3-year
Phase - Heaters 1
Pool Type In Ground
Product Dimensions 31 " x 28 " x 21 "
Product Height 31 in
Product Length 21 in
Product Weight 135 lb
Product Width 28 in
Rear Clearance - Heaters 0"
Refrigerant Yes
Series Heaters Universal HC Series
Shipping Dimensions 40 " x 24 " x 31 "
Shipping Weight 168 lb
Side Clearance - Heaters 12"
Silent Mode No
Sub Brand N/A
Voltage - Heaters 120/240V

Questions & Answers

15 answered question(s)

06/24/26

Q: Why is write if

A:
Hello, please use our website's dealer locator to find the closest Hayward Authorized Service Center(HASC). A HASC may be needed to address this issue. Link to dealer locator: https://hayward.com/dealerlocator IF is an ignition failure code

By Hayward Support

06/24/26

Q: Does this heater work with a remote?

A:
Hi, this heater can be controlled by any of our Omni series of controllers, and by the majority of our competitors controllers as well.

By Hayward Support

06/24/26

Q: I see that the HDF400 has a smaller footprint than the FDN400. Other than size what's the difference? I need a 400,000 BTU heater one way or another. Space is an important consideration for me. Also, how much space must there be between the heater and the wall (back of the chimney) to work properly? Thanks in advance!

A:
Hi, efficiency and heat capacity are the same for both of our 400,000 BTU heaters. Clearances are outlined on the manual for the HDF400 Here's a link to it. https://hayward.com/media/akeneo_connector/asset_files/5/1/51300803801_RevD_3ae9.pdf

By Hayward Support

06/24/26

Q: I am trying to replace an H150 older unit. Which newer heater is the right choice?

A:
Hi, we would recommend the H150FD for a replacement. Hi, you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: how do I register the warranty card

A:
Hi, you can register your product on our website Hayward.com by clicking on the support tab, then clicking on Warranty and then scroll to the bottom left where there is a section labeled "Register a Product"

By Hayward Support

06/24/26

Q: For a 494 sq ft surface area, 15000 gallon volume, 60 F ambient, no wind, how long will it take to heat to 90 F with a 200,000 btu / hr gas fired unit? Is the HC series meant for direct exposure in ambient? What is the minimum waterflow rate through the HC series, 200,000 btu / hr unit? Any special ordering instructions for salt water pool? For out door installation, is an exhaust pipe required?

A:
Hi, the H200FD heater is an 84% efficient heater, so for every 200,000 BTU's of fuel you use you will get 168,000 BTU's of heat out. A BTU is the amount of heat necessary to raise the temperature of one pound of water 1 degree. A 15,000 gallon...

By Hayward Support

06/24/26

Q: What size pool heater do I need for a 12,000 gallon above ground pool?

A:
Hi, our above ground gas heater is the H135. We also have a couple of heat pumps that would work well for you. The HP50HA2 and the HP70HA2 would both be a good fit.

By Hayward Support

06/24/26

Q: my heater keeps blowing the IBC board i need help trouble shooting this problem

A:
Hi, for help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: good morning, so we installed a HAY-15-7745 but when the filter kicks on the heater comes on with out the app asking to to come on. Any ideas why ?

A:
Hi, for help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: My pool was completed 2022 by Omnia outdoors Georgetown Texas. They are now out of business. I wanted to check if my heater HDF-400 is registered. S/N 21132112509249001

A:
Hi, someone from our Technical Service Department will contact you via email.

By Hayward Support

06/24/26

Q: I registered my HDF 400 pool heater warranty but cannot find it on the website. Registered warranty heater May 25, 2024. Purchased heater from Brazos Valley Pools & Spas May 22, 2024. Serial number: 21132310551322001

A:
Hi, someone from our Technical Service Department will contact you via email.

By Hayward Support

06/24/26

Q: We had pinch a penny install our hdf400 heater back in June of 2024 and now it puffs hot air for about 15 seconds as it trys to ignite and then shuts off to repeat the cycle again without staying on. You can feel puffs of hot air come out but it won't ignite. We had our tank refilled thinking it was from lack of fuel and it is still failing to fire up. What should I try next that will be covered by warranty?

A:
Hi, for help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: Why is it Hayward shows products here without sufficient necessary information about it? A dual fuel pool heater for example, Which fuels? Electric, Propane. Natural Gas? All Propane and Natural gas can use either, So the assumption is, the Dual Fuel is Heat pump or other electric and gas???

A:
Hi, the HDF Dual Fuel heaters come equipped for use with either natural gas or propane simply by changing the (supplied) mixing orifice. All gas heaters sold in the US today require electricity as well. Our UHS line of heaters come in natural OR propane...

By Hayward Support

06/24/26

Q: We have a 10-year old H400FDN that has failed. I have been told that this model has been discontinued. Is the H400FDN I see listed on your site the same as our model?

A:
Hi, yes it is. We still build the H400FDN. It is our most popular heater!

By Hayward Support

06/24/26

Q: Hello, I'm a Certified General Contractor in Tallahassee, Florida building a new construction RV/Garage/pool house along side a separate pool builder. The pool builder installed an HDF400 heater on a concrete pad with the exhaust facing the side garage wall and a vinyl window at a distance of approximately 14" from exhaust to vinyl window frame. Reading through the manufacturer specifications it says "Side Clearance - 12." Is this side clearance of 12" applicable to the exhaust side of the heater and its distance to combustible materials? Thank you.

A:
HI, this sounds like an incorrect installation. I would suggest calling the code enforcement agency for your area. The proximity to the window makes this a dangerous installation that you will want to document for your protection.

By Hayward Support
