Features

Hayward Universal H-Series gas heaters are the “universal” energy efficient remedy for any new or existing pool or spa. An industry-leading hydraulic design reduces circulation pump run time to provide energy savings of up to 18% when compared to less efficient competitors. The energy efficiency of the Universal H-Series gas heater combines with environmentally friendly low NOx emissions, a standard cupro nickel heat exchanger, and ultimate installation flexibility to responsibly heat a pool or spa today and for years to come.

Features and Benefits

Standard cupro nickel heat exchanger
Excellent salt water and chemical corrosion resistance
Exclusive "Totally Managed" cupro nickel heat exchanger water flow
Same water velocity through all tubes for faster heating
Patented header by-pass design
Reduction in pump run-time results in significant cost savings
2" x 2 1/2" CPVC union plumbing connections
Forced draft system constantly moves air through the combustion chamber at a precise flow rate, eliminating the need for a high-wind stack
Low NOx emissions - meets clean air quality standards

NOTE: Hayward Universal H-Series heaters meet or exceed the South Coast Air Quality Management District (SCAQMD Rule 1146.2) Low NOx emissions standards in all Low NOx areas that apply the SCAQMD standard.

Active Defrost	No
Application	New Construction, Aftermarket
Boost Mode	No
Brand	Hayward
Channel	Open Line
Circuit Amps	5.5
Compressor Speed	N/A
Cooling Capability	No
Fuel Type	Natural Gas (NA)
GTIN	610377387194
Heating Capacity (BTU/hr)	150,000
Hertz - Heaters	60 Hz
Kilowatts	44 kW
Warranty - Labor	None
Low Ambient Operation	Yes
Master Carton Qty	1
Maximum Breaker Size (Amps)	15
Minimum Operating Temperature	40 °F
Pallet Qty	1
Warranty - Parts	1-year
Phase - Heaters	1
Pool Type	In Ground
Product Dimensions	24 " x 19 " x 29.5 "
Product Height	24 in
Product Length	29.5 in
Product Weight	135 lb
Product Width	19 in
Rear Clearance - Heaters	6"
Refrigerant	No
Series Heaters	Universal H-Series
Shipping Dimensions	30.6 " x 32.8 " x 33.3 "
Shipping Weight	150 lb
Side Clearance - Heaters	12"
Silent Mode	No
Voltage - Heaters	120/240V
Water Flow Rate Max	125
Water Flow Rate Min	20

Questions & Answers

9 answered question(s)

PATRICK HAVRILKO Verified User

06/24/26

Q: How does the gas ignition work? ie: Pilot light, Electric, etc What kind of electrical hook up does it need? ie: 120v, 240v? Does it come with a plug for electrical?

A:

Hi, the heater uses a hot surface igniter, and it can be wired either 120 or 240 volts.

By Hayward Support

Michael Hinners Verified User

06/24/26

Q: Please provide availability and pricing. I am replacing an existing H150 heater that has developed worsening tubing leaks due to corrosion. Is there a local distribution center/dealer in the San Diego area? When I entered my Lemon Grove 91945 location nothing came up. There is a nearby Leslie's Pool Supply that I have purchase other Hayward valves and products, but I would like to buy direct since I will be doing the installation as previously done.

A:

Hi, we do not sell direct. You can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Donna Verified User

06/24/26

Q: I live in the Chicago area, with cold and snowy winters. Should I put a cover over my Swimpro 150k heater? If so, any recommendation on best winter cover to buy. Thanks

A:

Hi, your heater is designed to be out in the elements, but you should make sure you drain all the water out of it as outlined in the manual.

By Hayward Support

Kai Verified User

06/24/26

Q: Can this heater be installed with Omnilogic panel? asking for clarification. Thank you.

A:

Hi, yes any of the OmniLogic base systems can control any of our heaters.

By Hayward Support

Kelly Verified User

06/24/26

Q: if I have this unit and I need to change it to LP what would be the charge for that

A:

Hi, we do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Kelly Verified User

06/24/26

Q: can I change a natural gas pool heater to an LP gas

A:

Hi, the UHS heaters can be converted, but it should only be done by a certified gas installer. You can find a list of Hayward Authorized Dealers who can do this by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

David Diller Verified User

06/24/26

Q: I have a Hayward Swim Pro Model # SW150DHN, Serial number 21132104107331001 that is leaking water. I believe it is coming from the Heat Exchanger Assembly. When I search Model SW150DHN, I get information about H150FD. Are they the same unit?

A:

Hi, yes the heat exchanger would be the same on both of these heaters.

By Hayward Support

Pat Verified User

06/24/26

Q: Can I get a remote WiFi controller?

A:

HI, there is no heater specific remote available for our heaters. That being said, you can connect this heater to one of our OmniLogic control systems and you will have access to the remote capability of the controller. To find a local pool company that...

By Hayward Support

Terry M Verified User

06/24/26

Q: How many DREAM cocks are on this heater for winter prep I find the only one

A:

There is only one drain on these heaters. You can also disconnect the unions and blow air through the heat exchanger.

By Hayward Support
