TriStar XE Pump, 1.85 HP

Name: TriStar XE Pump, 1.85 HP
SKU: SP3210X15XE
Availability: InStock

Hayward

SKU: SP3210X15XE

TriStar XE ultra-high efficiency pumps are built to deliver maximum energy savings while cutting equipment costs by more than a third.

Replacement SKU: VSP32815

Features

TriStar XE ultra-high efficiency pumps are built to deliver maximum energy savings while cutting equipment costs by more than a third. With selectable speed options, pool owners can customize their pump settings (and savings) without having to pay for more options than they need. With its easy installation, dual-voltage capability and durable design that's up to 30% lighter than competitive VS models, TriStar XE is the best drop-in solution when replacing older single speed TriStar models.

Features and Benefits

Industry-leading efficiency exceeds DOE benchmarks and efficiency of many competitive VS pumps
Easily programmable with up to 6 selectable speeds
Dual-voltage capability (230V/115V) offers more versatility for installation
Chemical-resistant Viton® seal offers improved resistance against chemical imbalances
Simple installation includes standard 2" x 2.5" unions and doesn't require any additional equipment

EXPERT LINE products can only be purchased through your local pool professional or in-store. Exclusions, other terms, and conditions may apply.
3+ Year Parts and Labor Warranties*

*When sold by a Hayward Rewards® partner. Exclusions, other terms and conditions may apply.

NSF Certified

NSF’s comprehensive inspection, testing and certification services ensure our products comply with all major state and provincial health codes, as well as model building and construction codes.

Application	New Construction, Renovation, Aftermarket
Brand	Hayward
Channel	Expert Line
DOE Compliant	Yes
GTIN	610377434461
Warranty - Labor	1-year
Master Carton Qty	1
Motor Type	ODP
Number of Speeds	Multi Speed
Warranty - Parts	3-year
Phase	Single Phase
Pool Type	In Ground
Quick Clean Button	No
Remote Mount Display	No
Rotatable Display	No
Shipping Dimensions	16.3 " x 13.3 " x 30.5 "
Shipping Weight	39.8 lb
Total HP	1.85 HP
Twist Lock	No
Voltage at 60 Hz	230/115
WEF	8.5 / 8.4
Wiring Type	Field Wire

Questions & Answers

5 answered question(s)

Jason Verified User

06/24/26

Q: Which is the optimal filter for this pump and a 25k gallon pool?

Hi, filtration needs vary with location, and bather load. Contact a local Hayward Authorized Dealer for further assistance in choosing the right filter for your location. You can find a list of them by clicking on the Dealer Locator tab on the home page...

By Hayward Support

Ronald Verified User

06/24/26

Q: What is the replacement model for SP32185Z1ECM1

SPX3210X15XEPE

By Hayward Support

Danny Addabbo Verified User

06/24/26

Q: I have we a sp32102ee which I'm told is no longer available. Is the direct replacement a sp3210x15xe. It looks different but I'm told that's the replacement.

Yes, that would be a good replacement powerend. We can no longer sell pumps over 1 hp that are not variable speed.

By Hayward Support

Earl Verified User

06/24/26

Q: how do you program the pump

Hi, instructions for programming the pump are included in the manual. Attached is a link to the manual, and also a quick start guide that has some programming in it. https://hayward.com/media/akeneo_connector/asset_files/I/S/IS3200XE_REV_B_8d8c.pdf ...

By Hayward Support

Terry Verified User

06/24/26

Q: Does this integrate with Hayward goldline prologic

Hi, you can use a ProLogic controller to turn the pump off and on, but the XE pumps are designed to operate as a stand alone pump. The VS function cannot be controlled by the controller.

By Hayward Support
