Name: TriStar VS Pump, 2.7 HP (Open Line)
SKU: W3SP3206VSP
Availability: InStock

Features

According to EPA ENERGY STAR® 3rd party test data, Hayward TriStar® VS variable speed pool pumps are the most energy efficient on the market. Designed for medium to large pools, they can save up to 90% on energy costs or as much as $1500 per year when compared to single-speed pool pumps.

Features and Benefits

Permanent magnet, totally enclosed fan cooled (TEFC) motor delivers maximum energy efficiency and reliability
Exceptionally quiet compared to single-speed pumps
Fully programmable touch-pad control can be rotated to four different positions or mounted to the wall for more convenient access
Universal compatibility: operates independently, with Hayward automation, or with competitive systems (via relay control)
Extra-large basket design ensures easy leaf and debris removal and extends time between cleanings

Brand	Hayward
Channel	Open Line
DOE Compliant	Yes
GTIN	610377388085
Warranty - Labor	None
Master Carton Qty	1
Motor Type	TEFC
Number of Speeds	Variable Speed
Warranty - Parts	1-year
Phase	Single Phase
Pool Type	In Ground
Quick Clean Button	No
Remote Mount Display	No
Rotatable Display	No
Shipping Dimensions	16 " x 13.6 " x 30.1 "
Shipping Weight	66 lb
Total HP	2.7 HP
Twist Lock	No
Voltage at 60 Hz	230/115
WEF	7.3 / 10.1
Wiring Type	Field Wire

Questions & Answers

15 answered question(s)

Jim Argir Verified User

06/24/26

Q: bought pump last season and stored pump inside for the winter. Pump has been running for 2 weeks and just stopped working. Its totally dead. What is the warranty and were do I send it to get repaired. THANKS,

A:

Hello, please use our website's dealer locator to find the closest Hayward Authorized Service Center(HASC). A HASC may be needed to address this issue. Link to dealer locator: https://hayward.com/dealerlocator

By Hayward Support

Richard Bennett Verified User

06/24/26

Q: i am looking for an operators manual for my pump. web says one is not available. where can i get one? thanks

A:

Hi, someone from our Technical Service Department will contact you via email.

By Hayward Support

Fabiola Verified User

06/24/26

Q: What is the minimum and maximum GPH it can provide?

A:

Hi, at minimum speed it could be as little as 20 or so gpm and at max speed it could be as much as 200 gpm. It depends on the resistance to flow of the plumbing and other components of the pool system. Filters, heaters, etc.

By Hayward Support

Chris Wilson Verified User

06/24/26

Q: What is the recommended sand filter to use with this?

A:

Hi, we would not recommend any filter smaller than the S244T or S244S for this pump. Contact a local Hayward Authorized Dealer for help in determining the correct filter for your pool. You can find a list of them by clicking on the Dealer Locator tab...

By Hayward Support

Ryan C. Verified User

06/24/26

Q: Will this work with the older pro logic system? My prior pump was the sp3400vsp

A:

Yes it will.

By Hayward Support

Keith Clark Verified User

06/24/26

Q: Hi, I see on another website (Amazon) that this pump only pumps 40 gallons per minute? Surely this is a mistake? Other pumps go as high as 240Gpm Thanks! Keith

A:

Hi, you are correct. This pump will deliver 160 gpm at 40' of total dynamic head.

By Hayward Support

Trevor Verified User

06/24/26

Q: Can this pump work with my old Hayward PL-PS-8?

A:

Yes it will!

By Hayward Support

Hector Verified User

06/24/26

Q: Hi , can I just buy just the motor without the pump?

A:

Hi, there is a powerend available. It is the pump with the motor mounting plate, and impeller. SPX3206Z1VSPE. We do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of...

By Hayward Support

Mark M Verified User

06/24/26

Q: do you have a wiring diagram for Hayward AQ-SOL-LV with Hayward W35P3206V pump?

A:

Hi, the AQ-SOL-LV is not actually designed to control a variable speed pump, but you can wire a timer to the control that will turn the pump off and on. Wiring is shown in the manual. Link attached https://hayward.com/media/akeneo_connector/asset_files...

By Hayward Support

Jennifer Elms Verified User

06/24/26

Q: The display on my pump stopped working. I Bought it 10/18. WE have replaced the breakers and verified that it is getting power.

A:

Hi, for help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Patti Hoaglund Verified User

06/24/26

Q: My Hayward Tristan 2.7 hp variable speed pump has stopped working. I need a replacement for my pool that is not quite a year old. Would you possible have one in stock?

A:

Hi, if your pump is less than a year old the pump should still be under warranty. Contact a local Hayward Authorized Service Center for help in determining the issue. If it is still under warranty and the issue is related to a defect in the pump they...

By Hayward Support

JIM BARRETT Verified User

06/24/26

Q: hello Hayward, i had my pool built in 2006 with a Hayward Auquaplus PS-4 controller and a 2.0 hp Hayward Northstar pump and motor. Everything is still working except i need a new motor and was wondering if i can put the 2.7 Tristar variable speed assembly in place and still use all the same old features of the PS-4 controller. the plumbing looks to be a simple remove and replace, or is it? and how about the wiring hookup, is it simple with just programing done on the new tristar controller then? Thank you, jim

A:

Hi, the Tristar 950 will connect no problem to your older controller. Your installer can make the necessary adjustments to programming.

By Hayward Support

Jeff McCormick Verified User

06/24/26

Q: Thank you for the age response. Is the sp 3207x10xe still the right considering this information. I did not mention the filter which is a Pentair S7M120 and pool size is 10,000 gallons. I do not want to undersized so not sure if the additional information is important. Jeff McCormick

A:

Hi, you should contact a local Hayward Authorized Pool Professional for help in choosing the correct pump for your situation. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Jeff McCormick Verified User

06/24/26

Q: Thank you for the response. You just suggested a SP3207X10XE to replace my old 1hp super two pump. The pump is still functioning but leaking at the housing. Do you have an idea of the age. I did not mention the filter which is a Pentair S7M120 and pool size is 10,000 gallons. I do not want to undersized so not sure if the additional information is important. Jeff McCormick

A:

Hi, there is no way to tell the age of the pump without the serial number. We built them for at least 20 years, but have not built them since 2020.

By Hayward Support

Jessie Verified User

06/24/26

Q: Is the SP3206VSP still available & if so, still warrantied ?

A:

Hi, the SP3206VSP is no longer available, and has been replaced with the W3SP3206VSP. It has a 3 years parts, no labor warranty

By Hayward Support
