ProSeries Plus 31" Sand Filter - Side Mount (2" Slide Valve Included)

Hayward

SKU: S311SXV

With all the ProSeries advanced features, ProSeries Plus filters are designed to meet the needs of the most demanding applications including large residential and semi-commercial pools, in-floor cleaning systems, solar heating systems and water features.

Features

Incorporating the many advanced features of ProSeries top-mount and side mount sand filters, the ProSeries Plus satisfies the requirements of the most demanding installations, including pools installed with in-floor cleaning systems, spas, fountains or solar heating systems.

Features and Benefits

  • Durable, flanged inspection cover provides convenient access to top of side mount filters
  • Flange clamp design allows 360° rotation of valve to simplify plumbing
  • Top diffuser ensures even distribution of water over the top of the sand media bed. All internal piping is 2" to give smooth, free-flowing performance
  • Large pressure sand/water drain for rapid winterizing or servicing
  • Unitized, corrosion-proof, spherical filter tank molded of rugged, colorfast polymeric material for maximum strength and longer life
  • Optional valve and coupling selections for plumbing ease and versatility. Choose from 6-position VariFlo® valve, 2-position slide valve or 1 1⁄2" SKT x 2" SLIP connectors for multiple (tandem) filter installations
  • Precision engineered umbrella-fold self cleaning laterals for balanced flow and backwashing, plus easy serviceability
  • EXPERT LINE products can only be purchased through your local pool professional or in-store.  Exclusions, other terms, and conditions may apply.
  • 3+ Year Parts and Labor Warranties*

*When sold by a Hayward Rewards® partner. Exclusions, other terms and conditions may apply.

Application New Construction
Backwash Flow Rate 99 GPM
Brand Hayward
Cartridge No
Channel Expert Line
Design Flow Rate 99
Drain Port Size (Inches) 1.5
Effective Filtration Area 4.95 ft.²
Filter Type Sand
Footprint 31 x 31"
GTIN 610377056892
Labor Warranty 1-year
Master Carton Qty 1
Maximum Working Pressure 50 PSI
Number of Filter Elements N/A
Pallet Qty 1
Parts Warranty 3-year
Pool Type In Ground
Pressure Gauge Yes
Product Dimensions 38.625 " x 31 " x 31 "
Product Height 38.625 in
Product Length 31 in
Product Weight 78 lb
Product Width 31 in
Public Design Flow Rate 99 GPM
Residential Design Flow Rate 99
Sand Capacity 350 lbs.
Series Filters ProSeries Plus
Shipping Dimensions 37 " x 31 " x 31 "
Shipping Weight 84 lb
Side Clearance - Filters 18"
Tank Type Polymeric Resin
Turnover - 10 Hours 59,400 GPM
Turnover - 8 Hours 47,520 GPM
Valve Included 2" Slide Valve
Vertical Clearance - Filters 18"
Parts Details

Click on the part number in the diagram to display the details.

Line Drawings

ProSeries Plus Charts
