Features

Adjustable speed options create powerful cost savings without a lot of hassle. And with easy installation and dual-voltage capability, MaxFlo XE is the best way to install an affordable pump that complies with Dept of Energy regulations in any new or existing pool.

Features and Benefits

Industry-leading efficiency exceeds DOE benchmarks and performance of many competitive VS pumps
Easily programmable with up to 6 selectable speeds
Easy-access control toggles between speeds at the touch of a button
Dual-voltage capability (230V/115V) for versatile installation
Simple installation with shorter length than smaller models, standard 1.5" x 2" unions and no additional equipment requirements

EXPERT LINE products can only be purchased through your local pool professional or in-store. Exclusions, other terms, and conditions may apply.
3+ Year Parts and Labor Warranties*

*When sold by a Hayward Rewards® partner. Exclusions, other terms and conditions may apply.

NSF Certified

NSF’s comprehensive inspection, testing and certification services ensure our products comply with all major state and provincial health codes, as well as model building and construction codes.

Application	New Construction, Renovation, Aftermarket
Brand	Hayward
Channel	Expert Line
DOE Compliant	Yes
GTIN	610377434416
Warranty - Labor	1-year
Master Carton Qty	1
Motor Type	ODP
Number of Speeds	Multi Speed
Warranty - Parts	3-year
Phase	Single Phase
Pool Type	In Ground
Quick Clean Button	No
Remote Mount Display	No
Rotatable Display	No
Shipping Dimensions	13.4 " x 9.9 " x 31 "
Shipping Weight	33.64 lb
Total HP	2.25 HP
Twist Lock	No
Voltage at 60 Hz	230/115
WEF	8.4 / 8.7
Wiring Type	Field Wire

Questions & Answers

12 answered question(s)

Bill Crescenzo Verified User

06/24/26

Q: I have a max flo xe variable pump that will not go into program mode. Tye green light is steady.

A:

Hi, for help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Al Campbell Verified User

06/24/26

Q: I have a maxflo xe variable speed 2.25/2.65 hp model M48AB51A04. The front seal leaked right away, but I waited until Fall closing before replacing the seal. However, I cannot find this model on the web so I can order the correct part. Where can I find the seals to replace them?

A:

Hi, we do not sell direct. You can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com The part number for the MaxFlo seal is SPX2700SA

By Hayward Support

Todd W. Verified User

06/24/26

Q: I have a Max Flo XE 1.65hp - SKU: SP2310X15XE. Pump installed new in July of 2023. Very quiet when installed. Currently very noisy (September 2024) due to a leak. Leak repaired but motor still very loud. Can the variable speed motor bearings be replaced? Can you purchase only the motor without the strainer housing/impeller, etc?

A:

Hi, yes you can. For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

David Verified User

06/24/26

Q: What replaces a sp2310x15

A:

Hi, since the federal DOE has outlawed sales of single speed pool pumps of greater that 1 hp a variable speed pump is your best replacement. The SP2610X15XE is the best replacement for this pump.

By Hayward Support

John Dick Verified User

06/24/26

Q: Thank you again for your response to my earlier question - I have a follow on question re replacing a a 1.2 HP Max-flo pump model number S48H2N122B3 - the replacement model you suggested ( MaxFlo XL SP2307X10 1.25 hp ) looks good but unfortunately is a couple of inches longer than my current configuration and won't fit inside the pump / irrigation box that houses the equipment. I have managed to disassemble the unit and the impeller housing unit looks serviceable (might need a new o ring) - is there a motor only unit that you could recommend that would fit the impeller assembly ? Would need a 4 bolt connection and the motor unit needs to be about 12 inches long ? Regards John 704-453-6453

A:

Hi, For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

John Dick Verified User

06/24/26

Q: Hi - I have a 1.2 HP Max-flo pump model number S48H2N122B3 that appears to have passed on to the great pond in the sky. What would be the modern equivalent please ? I have 1.5 inch pipes feeding 3 burble fountains in a water feature. Regards, John 704-453-6453 johntdick@aol.com

A:

Hi, the MaxFlo XL SP2307X10 1.25 hp should be a good replacement for your pump.

By Hayward Support

Kumar Verified User

06/24/26

Q: I would like to replace my hayward max flo 11 pump. 1.5 hp inground pump. What do you recommend

A:

HI, the MaxFlo SP2310X15XE variable speed pump will be a good fit.

By Hayward Support

Marie Verified User

06/24/26

Q: what size connector hoses are used?

A:

Hi, this pump is designed for 1 1/2" or 2" plumbing.

By Hayward Support

Kirk Williams Verified User

06/24/26

Q: I recently had a new pool and Hayward pump installed. Is it necessary to have a timer for this pump? Will adding a timer affect the life of the motor? I live in southern Florida so the pump will be running most of the year.

A:

HI, your MaxFlo XE pump has timers built into it already. To understand how to use them consult the manual or contact a local Hayward Authorized Dealer for help.

By Hayward Support

Rajai Verified User

06/24/26

Q: Can I schedule running time

A:

Hi, you cannot change the interval times for the XE pumps. Here is a link to the manual for this pump. https://hayward.com/media/akeneo_connector/asset_files/I/S/IS3200XE_REV_B_8d8c.pdf

By Hayward Support

Ramiro Verified User

06/24/26

Q: Good morning Can you tell me how turn off the system.

A:

Hi, if you would like to turn off the pump for an extended period of time the best way is to turn off the power at the breaker. If you would like to turn it off for a shorter period of time you can use the button on the pump. press and release the button...

By Hayward Support

Raymond Rodriguez Verified User

06/24/26

Q: I have a pump that is a maxflo ex 1.65 Is there any way to replace the button that controls the speed

A:

Hi, someone from our Technical Service Department will be in touch via email soon.

By Hayward Support
