Name: MaxFlo VS 500 Pump, 1.65 HP
SKU: SP23520VSP
Availability: InStock

Features

MaxFlo VS 500 is a simple drop-in upgrade for MaxFlo models up to 1.5 H.P. It features an upgraded dual voltage motor drive that delivers significantly quieter high-speed operation while maintaining optimal operating efficiency with increased reliability and product longevity. Also, a Viton® seal for long-lasting performance.

Hayward® VS Omni ultra-high efficiency pumps provide next generation energy efficiency plus smart control of the entire pad including pumps, heaters, lighting, salt systems, cleaners, water features, and spa settings. Each model is supplied with everything needed to install smart pool control: VS Control Pad, Hub, and a Smart Relay. Up to two additional Smart Relays can be purchased for even more control.

Features and Benefits

Delivers up to 80% energy savings*
Dual-voltage motor drive maintains optimal operating efficiency for long-lasting performance
Advanced, chemical-resistant Viton seal enhances durability in all environments
VS Omni model provides smartphone control for the entire pad
Up to two additional Smart Relays (HLH485RELAY) can be added for even more control options
Speed Range: 600-3450 RPM

NOTE: *Actual savings may vary based on comparison pump model, hours of operation, electrical rate and other hydraulic aspects such as plumbing size and length.

EXPERT LINE products can only be purchased through your local pool professional or in-store. Exclusions, other terms, and conditions may apply.
3+ Year Parts and Labor Warranties*

*When sold by a Hayward Rewards® partner. Exclusions, other terms and conditions may apply.

Application	New Construction, Renovation, Aftermarket
Brand	Hayward
Channel	Expert Line
DOE Compliant	Yes
GTIN	610377339384
Warranty - Labor	1-year
Master Carton Qty	1
Motor Type	TEFC
Number of Speeds	Variable Speed
Pallet Qty	15
Warranty - Parts	3-year
Phase	Single Phase
Pool Type	In Ground
Quick Clean Button	No
Remote Mount Display	No
Rotatable Display	No
Shipping Dimensions	16 " x 12.4 " x 30 "
Shipping Weight	51 lb
Total HP	1.65 HP
Twist Lock	No
Voltage at 60 Hz	230/115
WEF	10.2 /10.7

Questions & Answers

15 answered question(s)

Michael Walsh Verified User

06/24/26

Q: We own a Max Flo VS 500 SP23520VSP pump that is out of warranty [7 years old] and on startup the motor is making noticeable noise. Our pool cleaning person believes the bearings are going out. Is this a serviceable item, and if not, can the motor end of the pump [without control panel] be purchased separately instead of purchasing an entire pump?

A:

Hi, yes the motor end can be replaced separately. SPX2303Z!VSPE is the part number. We do not sell directly, but you can find a local Hayward Authorized Dealer by clicking on the Dealer Locator tab on our home page of our website, Hayward.com Link to...

By Hayward Support

SRowe Verified User

06/24/26

Q: Hello. Pump hums, but does not start. What are possible causes and solutions?

A:

Hello, please use our website's dealer locator to find the closest Hayward Authorized Service Center(HASC). A HASC may be needed to address this issue. Link to dealer locator: https://hayward.com/dealerlocator

By Hayward Support

Sandra Lewis Verified User

06/24/26

Q: I bought this pump Saturday, 6.14.25, and didn’t receive a warranty card to send in. How do I warranty it?

A:

Hi, you can register your product on our website Hayward.com by clicking on the support tab, then clicking on Warranty and then scroll to the bottom left where there is a section labeled "Register a Product"

By Hayward Support

Eduardo tellecgea Verified User

06/24/26

Q: I own a hayward maxflow 500 oool pump. I need to buy tge external cooling fan that is attached to the exteriot shaft of the century motor. Pls advice.

A:

Hi, someone from our Technical Service Department will contact you via email.

By Hayward Support

Susan Verified User

06/24/26

Q: Is there a tool to get the pump cover off? Mine will not budge.

A:

Hi, there is not a tool. Make certain all pressure is released on the system, and try to tap it with a rubber mallet. If that does not work, contact a local Hayward Authorized Service Center for help with this. You can find a list of them by clicking...

By Hayward Support

Monica Young Verified User

06/24/26

Q: How do I backwash my pool filter?

A:

HI, that would depend on the type of filter and the valve that may be attached to it. For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website...

By Hayward Support

EjSal Verified User

06/24/26

Q: Is there a factory warranty ? If so how long ? Pump went out right at 5 years old !? We just moved into this home about 9 months ago. I don't think it should have to be replaced after 5 years. SMH

A:

Hi, this pump had a 3 years parts 1 year labor warranty.

By Hayward Support

Stacey Verified User

06/24/26

Q: How to keep the pump running 24/7. I do not want it cutting off . I want water moving continuously.

A:

Hi, consult the quick reference guide (link attached) for how to set timers. https://hayward.com/media/akeneo_connector/asset_files/Q/R/QRG3206VSP_RevC_90b6.pdf

By Hayward Support

EJ Verified User

06/24/26

Q: I cannot find my MSP system id to register my system in the app.

A:

Hi, give our Tech Support Group a call for help with this issue 908-355-7995

By Hayward Support

Betty Laquey Verified User

06/24/26

Q: How to change the time of day?

A:

Hi, please follow the steps outlined in the manual (link attached) to set the time. https://hayward.com/media/akeneo_connector/asset_files/1/0/1011781_RevB_e53b.pdf

By Hayward Support

Dan Verified User

06/24/26

Q: My lcd screen is unreadable but all of the buttons are working fine. Can I replace just the lcd screen?

A:

Hi, you will have to replace the entire display. SPX3200LCD We do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Mark Drennen Sr Verified User

06/24/26

Q: I had to remove my pump. After disconnecting power, I left the waterproof cover off, lifted the pump, and soaked the pump control circuit boards. Once soaked, and dried, will the boards still work? If not, where do I obtain replacement boards? The pump is about a year old. Max flow VS 1.65 THANK YOU!

A:

Hi, for help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

eric Verified User

06/24/26

Q: my display is clouded, can i replace just the display- the manual seems to suggest that this is part #spx3400dr4

A:

Hi, yes the display can be replace separately. For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Jason Mendez Verified User

06/24/26

Q: My Hayward run in 3450 watts but the flow is low

A:

Hi, check your pump basket to ensure it is clean. Also, check your filter pressure to ensure it is clean as well. Check valve positions to ensure they are open to and from the pump. If all of this is okay - For help with this contact a local Hayward ...

By Hayward Support

Bronwyne Bruwer Verified User

06/24/26

Q: How do I clean filter

A:

Hi, someone from our Technical Service Department will contact you via email.

By Hayward Support
