C-SPA Electric Heater 11 KW 240V
Hayward
SKU: CSPAXI11
Hayward electric spa heaters contain all of the sophisticated features and capabilities of heaters twice their size.
Features
Hayward electric spa heaters contain all of the sophisticated features and capabilities of heaters twice their size. The electric heaters fit into compact spaces — even under spa skirts or steps. Like all Hayward heaters, they are easy to install and service.
Features and Benefits
- 304 stainless steel tank and threaded head
- Safety sensor electric heating element
- Service-ease design gives simple access to internal controls
- Heater on indicator light
- UPS Shippable
- EXPERT LINE products can only be purchased through your local pool professional or in-store. Exclusions, other terms, and conditions may apply.
- 3+ Year Parts and Labor Warranties*
*When sold by a Hayward Rewards® partner. Exclusions, other terms and conditions may apply.
| Brand | Hayward |
|---|---|
| Channel | Expert Line |
| GTIN | 610377003957 |
| Heating Capacity (BTU/hr) | 37,534 |
| Hertz - Heaters | 60 Hz |
| Kilowatts | 11 kW |
| Warranty - Labor | 1-year |
| Master Carton Qty | 1 |
| Maximum Breaker Size (Amps) | 60 |
| Pallet Qty | 60 |
| Warranty - Parts | 3-year |
| Phase - Heaters | 1 |
| Pool Type | In Ground |
| Product Dimensions | 11.6 " x 6.25 " x 6.6 " |
| Product Height | 11.6 in |
| Product Length | 6.6 in |
| Product Weight | 14 lb |
| Product Width | 6.25 in |
| Series Heaters | Spa Heaters |
| Shipping Dimensions | 13.9 " x 8.6 " x 10.8 " |
| Shipping Weight | 12 lb |
| Sub Brand | N/A |
| Voltage - Heaters | 240V |
Line Drawings
Questions & Answers
15 answered question(s)
Please log in to submit a question.
Q: Reset button doesn't depress
By Hayward Support
Q: I am in Florida. Is there a code issue with using this in Florida. I have heard that resistance heaters are outlawed in some states.
By Hayward Support
Q: How long should a Hayward brand new heater take to heat up my spa?
By Hayward Support
Q: I have a Hayward Electric Spa Heater CSPA XI. My unground pool with attached spa was installed in 2017. This will be my third heater installed in the system, they keep shorting out. My first installer retired and I can't get the local pool companies to come out. My pool is 24x12 w/attached 6 person spa. Is this heater too small? Why do you think this keeps happening?
By Hayward Support
Q: Max flow rate?
By Hayward Support
Q: Can i use 100amp 240v for the CSpa11?
By Hayward Support
Q: My heater is under three years old and it will no longer turn on aside from when the pump is initially turned on for a few seconds, then clicks off. I contacted the authorized service company near me and they have been nonresponsive. What do you recommend? I do to resolve the issue?
By Hayward Support
Q: Hi, Could you tell me what Amp breaker is needed to run this heater? Its obvious that its a double pull 240V but I cant find anything on the Amps needed.
By Hayward Support
Q: What is the amps
By Hayward Support
Q: When I turn the CSPAXI11 knob on, turning past cold into warm or higher, there is a very loud buzzing sound. It sounds almost like an alarm coming from the unit. Please advise. Thanks, Rob
By Hayward Support
Q: No matter what heat temp I set my CSPA xl spa heater, it heats the water to 109. Tried turning down, but then the element wouldn’t turn on. Turn knob back up and heated to 109 again. Is there any adjustment so that I can get it to stay at 104.
By Hayward Support
Q: I purchased a house w an existing hayward cspa xl electric heater. I want to utilize the spa but not damage since I have not used it before. It has a dedicated pump seperate from the pool. It has a programmable timer to turn the spa pump on as needed. Obviously the pump has to circulate to move water thru the heater, but leaving the pump running 24/7 is not very efficient. My question is: when I turn on the thermostat to heat w the cspa xl does the heater also have an internal sensor to shut off when water is not flowing to avoid burning up the elements? For example: if I set my heat to full heat and set my timer to run pump from 5 til 9pm will the heater sense the stoppage of water flow outside of pump run time?
By Hayward Support
Q: Hooked up 220 wire to cspaxi -11 heater but it wont come on. When we took cover off there were two control wires a yellow and a blue that wasn’t hooked to anything so we didn’t know if that was possibly the reason why it won’t come on?
By Hayward Support
Q: The heater will only bring the water temperature to 95 degrees. Is there an adjustment to make the temperature hotter ?
By Hayward Support
Q: I need a replacement button for the reset temperature limiter
By Hayward Support
